About this course

UEEIC0014 - Develop, enter and verify programs in Supervisory Control and Data Acquisition systems

This course teaches you how to create and commission a SCADA interface and can be delivered as an accredited unit of competency or a non-accredited short course (please note UEEIC0015 and UEEIC0013 are pre-requisites).

This course starts by creating a SCADA project, setting up communications to a PLC, then continues with configuring common graphical objects, SCADA tag creation, and developing plant mimics. Participants will need to modify a provided PLC programming to suit new SCADA objects. The course culminates by creating and commissioning a SCADA interface to a Skills Lab training platform to set scope of work.

This course has been mapped to the UEEIC0014 - Develop, enter and verify programs in Supervisory Control and Data Acquisition systems, unit of competency. It includes all formal assessments which must be successfully completed under supervision of a TAE qualified assessor in order to obtain the accreditation.

It is recommended for:

• Entry level engineers,

• Technician Tradespeople

• Apprentices and Maintenance teams

• Operator

Participants should have a foundation-level knowledge of electrical concepts and working knowledge of at least one PLC, or have completed the Introduction to Automation program.

You will cover:

• Create a SCADA project

• Set up communications to a PLC

• Work through common graphical object use a SCADA tag creation

• Modify a provided PLC program to suit new SCADA objects

At the end of the course, you will

• Create and commission a SCADA interface to a SAGE training platform to a set scope of work

Available in: Citect

Course duration

4 days
